Description
Product Documentation
The following documents provide detailed information for installation, operation, and safety of the Aqua-Pure 3M AP902 High Flow Filtration System:
- Aqua-Pure 3M 900 Series High Flow Filtration Systems Spec Sheet
- 3M 900 Series High Flow Systems Manual
- 3M 900 Series SDS
- 3M AP902 Filtration System documentation for particulate filtration, suitable for residential and light commercial use
Features & Benefits
- Durable 304 stainless steel head supports sweat-in-place installation and provides strong corrosion resistance
- Equipped with 1-inch inlet and outlet connections for simple installation and high flow performance up to 20 gpm (75.7 lpm)
- Tested and rated for peak flow rates of 20 gpm (75.7 lpm), meeting the needs of most residential and light commercial applications
- Sanitary Quick Change (SQC) cartridge design allows fast replacement without the use of tools or filter wrenches
- Includes an electronic countdown timer refrigerator magnet to help indicate when cartridge replacement is approaching
- Constructed using FDA CFR-21 compliant materials for potable water applications
- Stainless steel head is supported by a 25-year limited warranty
Specification
- Part Number: 5621101
- Model Name: AP902
- 3M ID Number: 710007699
- Filtration Rate: 5 Micron
- System includes a head assembly with an integrated mounting bracket and one cartridge filter
- Inlet and outlet plumbing connections: 1-inch NPT
- Filter cartridge uses an o-ring seal design
- Maximum operating pressure: 125 psi (862 kPa)
- Maximum operating temperature: 100°F (37.8°C)
- Peak flow rate: up to 20 gpm (75.7 lpm)
- AP910R filter cartridge features non-woven pleated media
- System materials comply with FDA CFR-21 requirements
- Sanitary cartridge design prevents contact with filter media during replacement
- Case quantity: 1 (system or replacement cartridge)
- Replacement Filter Cartridge Part Number: 5621101 (Model Name: AP910R)
