Description
PRODUCT DOCUMENTATION
The following documents provide complete technical, installation, and usage information for the 3M ICE160-S water filtration system:
- 3M ICE160-S Spec Sheet
- 3M Water Filtration Systems for Food Services Brochure
- 3M Single Cartridge System Instruction Manual
FEATURES AND BENEFITS
The 3M ICE160-S system is designed to deliver consistent water quality while protecting food service equipment. It offers advanced filtration combined with built-in scale control for reliable performance.
- Designed for sediment, cysts, and chlorine taste and odor reduction
- Integrated scale inhibitor to protect equipment from clogging and scale buildup
- Includes head assembly with integral mounting bracket and pressure gauge
- Single cartridge filtration system for simplified maintenance
- Valve-in-head design for quick and easy filter replacement
- NSF certified for quality and safety assurance
SPECIFICATION
The 3M ICE160-S filtration system is engineered with precise specifications to meet commercial food service requirements.
- Model Number: ICE160-S
- Part Number: 5616303
- Nominal Micron Rating: 0.2
- Dimensions: 4-3/8″ x 17-5/8″ (11.1 cm x 44.8 cm)
- Inlet and Outlet Ports: 3/8” FNPT horizontal
- Cartridge Type: Sanitary Quick Change (SQC) encapsulated cartridge
- Capacity: 35,000 gallons (132,489 liters)
- Service Flow Rate: 3.34 gpm (12.6 lpm)
- Replacement Filter Cartridge Model Number: HF60-S
- Replacement Filter Cartridge Part Number: 5613405
- Case Quantity: 1 piece
