Description
PRODUCT DOCUMENTATION
The following documents provide detailed technical and product information for the 3M ICE265-S water filtration system:
- 3M ICE265-S Spec Sheet
- 3M Water Filtration Systems for Food Services Brochure
FEATURES AND BENEFITS
The 3M ICE265-S Commercial Series System is engineered for large ice machines and flakers, delivering consistent water quality and dependable equipment protection in demanding food service environments.
- Designed for ice machines producing up to 3,000 lbs (1,360.8 kg) and flakers producing over 4,800 lbs (2,177.7 kg) of ice
- Reduces sediment and chlorine taste and odor for improved ice quality
- Dual manifold system with integral mounting bracket and pressure gauge
- Includes two high-flow HF60-S filter cartridges
- Built-in scale inhibitor to help protect equipment from clogging and scale buildup
- Valve-in-head design for quick and easy filter replacement
- NSF certified for quality and safety assurance
SPECIFICATION
The 3M ICE265-S system is designed with specifications that support high flow rates and extended capacity for commercial ice production.
- Model Number: ICE265-S
- Part Number: 5624504
- Nominal Micron Rating: 3.0
- Dimensions: 16-7/8″ x 18-1/16″ (42.9 cm x 45.9 cm)
- Inlet and Outlet Ports: 3/4” NPT horizontal
- Cartridge Type: Sanitary Quick Change (SQC) encapsulated cartridge
- Capacity: 70,000 gallons (264,978 liters)
- Service Flow Rate: 6.68 gpm (25.3 lpm)
- Replacement Filter Cartridge Model Number: HF65-S
- Replacement Filter Cartridge Part Number: 5613409
- Case Quantity: 1 piece
